BLUETOOTH V4 BLE SENSOR



FEATURES

- RICH SENSOR OPTIONS: TEMPERATURE, HUMIDITY, PM2.5, CO, CO2, CH2O, VOC, PRESSURE, RFID
- BLE BEACON
- SUPPORT EXTERNAL I/O CONTROL INTERFACE, EX. PIR OR RELAY
- SUPPORT REAL TIME LOCATION SYSTEM (RTLS) APPLICATIONS
- CONFIGURABLE AUTO REPORT PERIOD AND POWER LEVEL


APPLICATIONS

- LOCATION SYSTEM: ASSET, PASSENGER, PATIENT, TRAILER
- ACCESS CONTROL: GARAGE, ENTERPRISES, BANK, VEHICLE, FACTORY, HOSPITAL,
- SUPERSTORE, SCHOOL, WAREHOUSE
- LOGISTIC MANAGEMENT, CARGO TRACKING, AIRPORT BAGGAGE MANAGEMENT
- LOCAL AREA REAL TIME LOCATION SYSTEMS (RTLS)
- ASSET MANAGEMENT, INTERNET OF THINGS (IOT) APPLICATIONS



SPECIFICATIONS(BLE READER)

* FREQUENCY BAND: 2.4GHZ ISM ( 2.40000 – 2.4835GHZ)
* MICROCONTROLLER: 32-BIT ARM CORTEX M0
* RANGE: MAX. 50 M IN OPEN SPACE
* TX POWER: MAX. 3 DBM
* TX CURRENT CONSUMPTION OF 15.6 MA (RADIO ONLY, 0 DBM)
* OPERATION TEMPERATURE: –40 °C TO +70 °C
* DIMENSIONS: 5.5 × 4 × 0.8 CM
* ANTENNA GAIN: MAX. 2 DB
